need 2 metal parts lathed - have cad files ready
I will use ai to edit or restore photos, or add to them

I'm looking for quotes for qty 2 aluminum lathed parts


text me if you can give a quote and do this locally near Mayfield/Paducah/Murray KY


I'm located in mayfield/sedalia KY
270-992-2093

I need a quote for qty: 2-4 of each of these parts:


Units: millimeters

Hole diameter: 1/4 inch = 6.35 mm
Hole radius: 3.175 mm
Clearance from each end of the 34mm cylinder to nearest hole edge: 3.000 mm
Hole center from each end: 6.175 mm
Hole centers measured from left end: 6.175 mm and 93.825 mm

Part 1, Qty 2:
- 34 mm diameter cylinder, 100 mm long
- 17 mm diameter shaft, 150 mm long
- Total length 250 mm
- Two vertical through holes in the 34 mm section

Mesh files were generated at high resolution for smooth round surfaces. SCAD source uses $fn=512.


The photo is of part 2. Part 1 is just the same except it doesnt have the 10mm x 34mm collar in the middle so its a little easier, so there are only 2 sizes 34mm and 17mm and total length is 250mm.
